XPI-108L Series Hydraulic Piston Pump 108 cc/rev for Hydraulic Systems

Verdrängung:108 cm³/U

Nenndruck:38 MPa (5511 psi)

Maximaldruck:42 MPa (6091 psi)

Maximaldrehzahl:1900 U/min

Drehrichtung:Links (entgegen dem Uhrzeigersinn)

Hersteller:BXHS

Produkttyp:Hydraulikkolbenpumpe

Produktserie:XPI-Serie Hydraulikkolbenpumpe

Verpackungsgröße:37*17*17

Bruttogewicht:18.00 kg

Verfügbarkeit: Auf Lager

152 Personen sehen sich dieses Produkt an

XPI-108L Series Hydraulic Piston Pump 108 cc/rev for Hydraulic Systems

XPI-108L Series Hydraulic Piston Pump 108 cc/rev for Hydraulic Systems

XPI-108L Series Hydraulic Piston Pump 108 cc/rev for Hydraulic Systems drawing image

The XPI-108L Series is a high-performance 108 cc/rev fixed displacement axial piston pump designed for demanding hydraulic systems. Operating at a rated pressure of 38 MPa with peaks up to 42 MPa, this left-hand rotation pump is engineered for durability and efficiency in heavy-duty applications ranging from construction machinery to agricultural equipment.

XPI-Serie Hydraulikkolbenpumpe Parameter
Verdrängung 32 cc/Umdr, 40 cc/Umdr, 45 cc/Umdr, 50 cc/Umdr, 63 cc/Umdr, 80 cc/Umdr, 25 cc/Umdr, 108 cm³/U
Nenndruck 38 MPa (5511 psi)
Maximaldruck 42 MPa (6091 psi)
Nenndrehzahl 1600 U/min
Maximaldrehzahl 1900 U/min
Drehrichtung Links (entgegen dem Uhrzeigersinn), Rechts (im Uhrzeigersinn)
Material Gusseisen
Struktur Schrägscheibe
Flanschversion ISO-4-Befestigungslöcher
Wellentyp H: Rechteckige Keilwelle

As a leading large-scale manufacturer of hydraulic solutions, we offer the XPI-108L Series Hydraulic Piston Pump, specifically engineered for high-pressure environments. With a displacement of 108 cc/rev and a maximum speed of 1900 r/min, this pump is ideal for concrete boom pumps, wheel loaders, mini-excavators, and truck-mounted cranes. We provide comprehensive manufacturing services including OEM, private labeling, and custom engineering to meet specific technical requirements. Our factory direct supply ensures competitive wholesale pricing for global markets. We are actively seeking long-term partnerships with distributors, wholesalers, agents, and traders worldwide. Whether you need bulk procurement or specialized customization for material handling and earthmoving equipment, our facility provides reliable support and consistent quality. Join our global distribution network and benefit from our extensive manufacturing expertise in industrial vehicle and agricultural hydraulic systems.
