Produktion & Lieferung
15–30 Tage Produktionsvorlaufzeit



The SD8 Series 3-spool manual sectional directional valve is designed for high-performance hydraulic systems, offering a rated flow of 80 L/min and operating pressure up to 250 bar. This versatile component is engineered for precise fluid control in demanding material handling, agricultural, and construction machinery.
| SD8-Serie Sektionalwegeventil Parameter | |
|---|---|
| Steuermethode | Manuell, Pneumatisch, Elektropneumatisch, Elektrohydraulisch, Magnet, Hydraulisch, Hydraulisch und Manuell, Kabel, Joystick, Magnet und Joystick, Manuell und Joystick |
| Steuerkolben | 1 Spule, 2 Spulen, 3 Spulen, 4 Spulen, 5 Spulen, 6 Spulen, 7 Spulen, 8 Spulen, 9 Spulen, 10 Spulen |
| Umgebungstemperaturbereich | -40 °C bis +80 °C (-40 °F bis +176 °F) |
| Strukturtyp | Schieberventil |
| Abschnitt | 1 Abschnitt, 2 Abschnitt, 3 Abschnitt, 4 Abschnitt, 5 Abschnitt, 6 Abschnitt, 7 Abschnitt, 8 Abschnitt, 9 Abschnitt, 10 Abschnitt |
| Bereich der Betriebsviskosität | 12 - 400 mm²/s (12 cSt bis 400 cSt) |
| Nennfluss | 90 l/min (23,8 US gal/min) |
| Maximaldruck | 315 bar (4600 psi) |
| Einlassanschluss | G1/2, G3/4, SAE 10 |
| Auslassanschluss | G1/2, G3/4, SAE 10, 3/4 NPT |
| Anschlussgröße | G1/2, SAE 10 |
As a leading manufacturer of hydraulic solutions, we present the SD8 Series Manual 3 Spool Sectional Directional Valve. Built for durability and precision, this valve features a robust sectional design and G1/2 | G3/4 porting, making it compatible with a wide range of equipment including mini-excavators, forklifts, wood splitters, and tractors. Our factory specializes in large-scale production, offering professional OEM, ODM, and customized manufacturing services to meet specific technical requirements. We provide flexible wholesale options and factory-direct supply to ensure competitive pricing and consistent quality for global markets. We are actively seeking long-term partnerships with professional distributors, wholesalers, regional agents, and international traders. Whether you need reliable private labeling (white label) services or bulk inventory for industrial applications, our factory is equipped to support your business growth with high-quality hydraulic components and dependable technical support.
