P80-AQF-G Series Monoblock Directional Valve: Wholesale & OEM

Steuermethode:Manuell

Steuerkolben:6 Spulen

Nennfluss:80 l/min (21,2 US gal/min)

Maximaldruck:250 bar (3600 psi)

Einlassanschluss:G3/4

Auslassanschluss:G3/4

Anschlussgröße:G1/2

Hersteller:BXHS

Produkttyp:Monoblock-Wegeventil

Produktserie:P80 Serie Monoblock-Wegeventil

Verpackungsgröße:26*36*11

Bruttogewicht:18.60 kg

Verfügbarkeit: Auf Lager

1051 Personen sehen sich dieses Produkt an

P80-AQF-G Series Monoblock Directional Valve: Wholesale & OEM

P80-AQF-G Series Monoblock Directional Valve: Wholesale & OEM

P80-AQF-G Series Monoblock Directional Valve: Wholesale & OEM drawing image

The P80-AQF-G Series Monoblock Directional Valve is a high-performance hydraulic control valve designed for a wide range of applications, including material handling, construction, earthmoving, agriculture, and industrial vehicles. This 6-section valve features a rated flow of 80 L/min and a maximum pressure rating of 250 bar, making it ideal for demanding applications.

P80 Serie Monoblock-Wegeventil Parameter
Steuermethode Manuell, Pneumatisch, Elektropneumatisch, Elektrohydraulisch, Magnet, Hydraulisch, Hydraulisch und Manuell, Kabel, Joystick, Manuell und Joystick
Steuerkolben 1 Spule, 2 Spulen, 3 Spulen, 4 Spulen, 5 Spulen, 6 Spulen, 7 Spulen
Umgebungstemperaturbereich -40 °C bis +80 °C (-40 °F bis +176 °F)
Strukturtyp Monoblockventil
Abschnitt 1 Abschnitt, 2 Abschnitt, 3 Abschnitt, 4 Abschnitt, 5 Abschnitt, 6 Abschnitt, 7 Abschnitt
Bereich der Betriebsviskosität 15 - 75 mm²/s (15 cSt bis 75 cSt)
Nennfluss 80 l/min (21,2 US gal/min)
Maximaldruck 315 bar (4600 psi)
Einlassanschluss G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Auslassanschluss G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Anschlussgröße G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

This Three Way Hydraulic Control Valve, part of the P80-AQF-G series, is a robust monoblock directional valve designed for demanding applications in industries such as material handling, construction, and earthmoving. This 6-section valve boasts a rated flow of 80 L/min and a maximum pressure rating of 250 bar, ensuring high performance and reliability. Its manual control method offers user-friendly operation. With a wide operating viscosity range of 15 to 75 mm²/s and an ambient temperature range of -40°C to +80°C, this valve is suitable for diverse operating environments. Its 6-spool design provides versatility and control for various hydraulic circuits. This valve is perfect for a wide range of machinery, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders. We offer wholesale and OEM options for this valve, catering to diverse needs. Contact us for more details and customized solutions.
