P40-G12 Directional Control Valve: Factory Direct & Customizable

Steuermethode:Manuell

Steuerkolben:3 Spulen

Nennfluss:40 l/min (10,5 US gal/min)

Maximaldruck:250 bar (3600 psi)

Einlassanschluss:G1/2

Auslassanschluss:G1/2

Anschlussgröße:G1/2

Hersteller:BXHS

Produkttyp:Monoblock-Wegeventil

Produktserie:P40-Serie Monoblock-Wegeventil

Verpackungsgröße:24*21*13

Bruttogewicht:6.60 kg

Verfügbarkeit: Auf Lager

2142 Personen sehen sich dieses Produkt an

P40-G12 Directional Control Valve: Factory Direct & Customizable

P40-G12 Directional Control Valve: Factory Direct & Customizable

P40-G12 Directional Control Valve: Factory Direct & Customizable drawing image

The P40-G12 4 Way Hydraulic Manifold Block is a robust and versatile directional control valve designed for a wide range of applications in material handling, construction, agriculture, and industrial vehicles. Featuring a monoblock design, 3 sections, and manual control, this valve offers a rated flow of 40 L/min and a maximum pressure of 250 bar. It is customizable to meet your specific needs.

P40-Serie Monoblock-Wegeventil Parameter
Steuermethode Manuell, Pneumatisch, Elektropneumatisch, Elektrohydraulisch, Magnet, Hydraulisch, Hydraulisch und Manuell, Kabel, Joystick, Magnet und Joystick, Manuell und Joystick, Magnetgesteuert und Seilzug
Steuerkolben 1 Spule, 2 Spulen, 3 Spulen, 4 Spulen, 5 Spulen, 6 Spulen, 7 Spulen
Umgebungstemperaturbereich -40 °C bis +80 °C (-40 °F bis +176 °F)
Strukturtyp Monoblockventil
Abschnitt 1 Abschnitt, 2 Abschnitt, 3 Abschnitt, 4 Abschnitt, 5 Abschnitt, 6 Abschnitt, 7 Abschnitt
Bereich der Betriebsviskosität 15 - 75 mm²/s (15 cSt bis 75 cSt)
Nennfluss 40 l/min (10,5 US gal/min)
Maximaldruck 250 bar (3600 psi)
Einlassanschluss G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Auslassanschluss G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Anschlussgröße G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

This 4 Way Hydraulic Manifold Block from the P40 series is a reliable and efficient solution for controlling hydraulic circuits. Its monoblock construction ensures durability and compact size. The valve features 3 sections and manual control, providing precise and responsive operation. With a rated flow of 40 L/min and a maximum pressure of 250 bar, it is suitable for demanding applications in various industries. The P40-G12 is designed to work with a wide range of operating viscosities and temperatures. It is ideal for use in telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, mini-excavators, skid steer loaders, compact wheel loaders, and wheel loaders. This valve is customizable to meet your specific requirements, making it a versatile choice for a variety of hydraulic systems.
