P40-G12-2OT Hydraulic Valve System | Performance & Reliability

Steuermethode:Manuell

Steuerkolben:2 Spulen

Nennfluss:40 l/min (10,5 US gal/min)

Maximaldruck:250 bar (3600 psi)

Einlassanschluss:G1/2

Auslassanschluss:G1/2

Anschlussgröße:G1/2

Hersteller:BXHS

Produkttyp:Monoblock-Wegeventil

Produktserie:P40-Serie Monoblock-Wegeventil

Verpackungsgröße:23*18*13

Bruttogewicht:5.00 kg

Verfügbarkeit: Auf Lager

1167 Personen sehen sich dieses Produkt an

P40-G12-2OT Hydraulic Valve System | Performance & Reliability

P40-G12-2OT Hydraulic Valve System | Performance & Reliability

P40-G12-2OT Hydraulic Valve System | Performance & Reliability drawing image

The P40-G12-2OT is a high-performance, reliable hydraulic pressure control valve designed for a wide range of applications, including construction, material handling, agriculture, and industrial vehicles. This 2-section, monoblock valve features a manual control method, rated flow of 40 L/min, and a maximum pressure of 250 bar.

P40-Serie Monoblock-Wegeventil Parameter
Steuermethode Manuell, Pneumatisch, Elektropneumatisch, Elektrohydraulisch, Magnet, Hydraulisch, Hydraulisch und Manuell, Kabel, Joystick, Magnet und Joystick, Manuell und Joystick, Magnetgesteuert und Seilzug
Steuerkolben 1 Spule, 2 Spulen, 3 Spulen, 4 Spulen, 5 Spulen, 6 Spulen, 7 Spulen
Umgebungstemperaturbereich -40 °C bis +80 °C (-40 °F bis +176 °F)
Strukturtyp Monoblockventil
Abschnitt 1 Abschnitt, 2 Abschnitt, 3 Abschnitt, 4 Abschnitt, 5 Abschnitt, 6 Abschnitt, 7 Abschnitt
Bereich der Betriebsviskosität 15 - 75 mm²/s (15 cSt bis 75 cSt)
Nennfluss 40 l/min (10,5 US gal/min)
Maximaldruck 250 bar (3600 psi)
Einlassanschluss G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Auslassanschluss G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Anschlussgröße G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

The P40-G12-2OT hydraulic pressure control valve is a robust and efficient solution for various mobile equipment. It offers a compact design with a 2-spool configuration, providing precise control over hydraulic systems. This monoblock valve is built for durability and reliability, operating within a wide viscosity range and temperature range. Its manual control method allows for simple and intuitive operation. With a rated flow of 40 L/min and a maximum pressure of 250 bar, this valve is suitable for a wide range of applications in construction, material handling, agriculture, and industrial vehicles. Some examples of its applications include telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders.
