Monoblock Valve P40-OW: Superior Quality and Exceptional Value

Steuermethode:Manuell

Steuerkolben:1 Spule

Nennfluss:40 l/min (10,5 US gal/min)

Maximaldruck:250 bar (3600 psi)

Einlassanschluss:G1/2

Auslassanschluss:G1/2

Anschlussgröße:G3/8

Hersteller:BXHS

Produkttyp:Monoblock-Wegeventil

Produktserie:P40-Serie Monoblock-Wegeventil

Verpackungsgröße:23*16*11

Bruttogewicht:3.00 kg

Verfügbarkeit: Auf Lager

1136 Personen sehen sich dieses Produkt an

Monoblock Valve P40-OW: Superior Quality and Exceptional Value

Monoblock Valve P40-OW: Superior Quality and Exceptional Value

Monoblock Valve P40-OW: Superior Quality and Exceptional Value drawing image

The P40-OW Hydraulic Cut Off Solenoid Valve is a high-quality, reliable valve designed for a wide range of applications, including material handling, construction, and agriculture. It features a monoblock design, rated flow of 40 L/min, and a maximum pressure of 250 bar.

P40-Serie Monoblock-Wegeventil Parameter
Steuermethode Manuell, Pneumatisch, Elektropneumatisch, Elektrohydraulisch, Magnet, Hydraulisch, Hydraulisch und Manuell, Kabel, Joystick, Magnet und Joystick, Manuell und Joystick, Magnetgesteuert und Seilzug
Steuerkolben 1 Spule, 2 Spulen, 3 Spulen, 4 Spulen, 5 Spulen, 6 Spulen, 7 Spulen
Umgebungstemperaturbereich -40 °C bis +80 °C (-40 °F bis +176 °F)
Strukturtyp Monoblockventil
Abschnitt 1 Abschnitt, 2 Abschnitt, 3 Abschnitt, 4 Abschnitt, 5 Abschnitt, 6 Abschnitt, 7 Abschnitt
Bereich der Betriebsviskosität 15 - 75 mm²/s (15 cSt bis 75 cSt)
Nennfluss 40 l/min (10,5 US gal/min)
Maximaldruck 250 bar (3600 psi)
Einlassanschluss G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Auslassanschluss G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Anschlussgröße G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

The P40-OW Hydraulic Cut Off Solenoid Valve is a superior quality and exceptional value monoblock valve designed for a variety of demanding applications. It features a manual control method, 1 section, 1 spool, and a rated flow of 40 L/min (10.5 US gpm). This valve is capable of handling pressures up to 250 bar (3600 psi) and operates with a viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt). Its ambient temperature range is -40°C to +80°C (-40°F to +176°F), making it suitable for a wide range of operating environments. Designed for reliability and durability, this valve is ideal for use in material handling, construction, and agriculture. It is compatible with a range of equipment including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders.
