Hydraulic Valve Manufacturer | P40-G12-1OT Directional Valve

Steuermethode:Manuell

Steuerkolben:1 Spule

Nennfluss:40 l/min (10,5 US gal/min)

Maximaldruck:250 bar (3600 psi)

Einlassanschluss:G1/2

Auslassanschluss:G1/2

Anschlussgröße:G1/2

Hersteller:BXHS

Produkttyp:Monoblock-Wegeventil

Produktserie:P40-Serie Monoblock-Wegeventil

Verpackungsgröße:23*16*11

Bruttogewicht:3.00 kg

Verfügbarkeit: Auf Lager

1050 Personen sehen sich dieses Produkt an

Hydraulic Valve Manufacturer | P40-G12-1OT Directional Valve

Hydraulic Valve Manufacturer | P40-G12-1OT Directional Valve

Hydraulic Valve Manufacturer | P40-G12-1OT Directional Valve drawing image

The P40-G12-1OT Directional Valve is a high-performance, manual control, monoblock hydraulic valve designed for various applications in construction, agriculture, and industrial vehicles. It features a rated flow of 40 L/min and a maximum pressure of 250 bar, making it ideal for telehandlers, forklifts, cranes, stackers, and more.

P40-Serie Monoblock-Wegeventil Parameter
Steuermethode Manuell, Pneumatisch, Elektropneumatisch, Elektrohydraulisch, Magnet, Hydraulisch, Hydraulisch und Manuell, Kabel, Joystick, Magnet und Joystick, Manuell und Joystick, Magnetgesteuert und Seilzug
Steuerkolben 1 Spule, 2 Spulen, 3 Spulen, 4 Spulen, 5 Spulen, 6 Spulen, 7 Spulen
Umgebungstemperaturbereich -40 °C bis +80 °C (-40 °F bis +176 °F)
Strukturtyp Monoblockventil
Abschnitt 1 Abschnitt, 2 Abschnitt, 3 Abschnitt, 4 Abschnitt, 5 Abschnitt, 6 Abschnitt, 7 Abschnitt
Bereich der Betriebsviskosität 15 - 75 mm²/s (15 cSt bis 75 cSt)
Nennfluss 40 l/min (10,5 US gal/min)
Maximaldruck 250 bar (3600 psi)
Einlassanschluss G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Auslassanschluss G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Anschlussgröße G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

The P40-G12-1OT Directional Valve is a robust and reliable hydraulic valve designed for demanding applications. It features a single spool and a single section with manual control, providing precise flow control and directional switching. Its monoblock construction ensures high strength and durability. With a rated flow of 40 L/min and a maximum pressure of 250 bar, this valve can handle a wide range of hydraulic systems. Its operating viscosity range of 15 - 75 mm²/s allows for use in various fluid conditions. The P40-G12-1OT is designed for a wide range of applications, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders. Its rugged construction and wide operating temperature range of -40°C to +80°C make it suitable for use in challenging environments.
