High-Quality P80-G34-G12-AT-3OT Directional Valve for Hydraulic Systems

Steuermethode:Manuell

Steuerkolben:4 Spulen

Nennfluss:80 l/min (21,2 US gal/min)

Maximaldruck:250 bar (3600 psi)

Einlassanschluss:G1/2

Auslassanschluss:G3/4

Anschlussgröße:G1/2

Hersteller:BXHS

Produkttyp:Monoblock-Wegeventil

Produktserie:P80 Serie Monoblock-Wegeventil

Verpackungsgröße:26*27*11

Bruttogewicht:13.40 kg

Verfügbarkeit: Auf Lager

1417 Personen sehen sich dieses Produkt an

High-Quality P80-G34-G12-AT-3OT Directional Valve for Hydraulic Systems

High-Quality P80-G34-G12-AT-3OT Directional Valve for Hydraulic Systems

High-Quality P80-G34-G12-AT-3OT Directional Valve for Hydraulic Systems drawing image

The P80-G34-G12-AT-3OT is a high-quality 4-section monoblock directional valve designed for hydraulic systems. It features a joystick control method, a rated flow of 80 L/min (21.2 US gpm), and a maximum pressure of 250 bar (3600 psi). This versatile valve is suitable for various applications, including material handling, construction, agriculture, and industrial vehicles.

P80 Serie Monoblock-Wegeventil Parameter
Steuermethode Manuell, Pneumatisch, Elektropneumatisch, Elektrohydraulisch, Magnet, Hydraulisch, Hydraulisch und Manuell, Kabel, Joystick, Manuell und Joystick
Steuerkolben 1 Spule, 2 Spulen, 3 Spulen, 4 Spulen, 5 Spulen, 6 Spulen, 7 Spulen
Umgebungstemperaturbereich -40 °C bis +80 °C (-40 °F bis +176 °F)
Strukturtyp Monoblockventil
Abschnitt 1 Abschnitt, 2 Abschnitt, 3 Abschnitt, 4 Abschnitt, 5 Abschnitt, 6 Abschnitt, 7 Abschnitt
Bereich der Betriebsviskosität 15 - 75 mm²/s (15 cSt bis 75 cSt)
Nennfluss 80 l/min (21,2 US gal/min)
Maximaldruck 315 bar (4600 psi)
Einlassanschluss G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Auslassanschluss G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Anschlussgröße G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

The P80-G34-G12-AT-3OT joystick hydraulic valve is a robust and reliable solution for demanding hydraulic systems. Its 4-section monoblock construction ensures high performance and durability. With a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure rating of 250 bar (3600 psi), this valve is capable of handling heavy-duty applications. The valve is designed to operate within an ambient temperature range of -40°C to +80°C (-40°F to +176°F) and a viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt). Its 4-spool configuration provides precise control over hydraulic functions. The P80-G34-G12-AT-3OT is ideal for a wide range of applications, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, and skid steer loaders. Its high-quality construction, robust performance, and versatility make it an excellent choice for manufacturers and users in various industries.
