The DCV58 series solenoid directional valve is a high-performance hydraulic valve designed for a wide range of applications, including construction equipment, material handling, and industrial vehicles. It features a 2-section design with a rated flow of 60 L/min and a maximum pressure of 350 bar. This reliable and durable valve is ideal for demanding applications.
| DCV58-Serie Sektionalwegeventil Parameter | |
|---|---|
| Steuermethode | Magnet, Magnetisch und manuell |
| Steuerkolben | 1 Spule, 2 Spulen, 3 Spulen, 4 Spulen, 5 Spulen, 6 Spulen, 7 Spulen, 8 Spulen, 9 Spulen, 10 Spulen, 11 Spulen, 12 Spulen |
| Umgebungstemperaturbereich | -40 °C bis +80 °C (-40 °F bis +176 °F) |
| Strukturtyp | Schieberventil |
| Abschnitt | 1 Abschnitt, 2 Abschnitt, 3 Abschnitt, 4 Abschnitt, 5 Abschnitt, 6 Abschnitt, 7 Abschnitt, 8 Abschnitt, 9 Abschnitt, 10 Abschnitt, 11 Abschnitt, 12 Abschnitt |
| Bereich der Betriebsviskosität | 15 - 75 mm²/s (15 cSt bis 75 cSt) |
| Nennfluss | 40 l/min (10,5 US gal/min) |
| Maximaldruck | 350 bar (5100 psi) |
| Einlassanschluss | G1/2, M22×1.5, SAE 10, 1/2 NPT |
| Auslassanschluss | G1/2, M22×1.5, SAE 10, 1/2 NPT |
| Anschlussgröße | G1/2, M22×1.5, SAE 10, 1/2 NPT |
The DCV58 series solenoid directional valve is a high-performance hydraulic valve designed for a wide range of applications, including construction equipment, material handling, and industrial vehicles. It features a 2-section design with a rated flow of 60 L/min (15.8 US gpm) and a maximum pressure of 350 bar (5100 psi). The valve is equipped with a solenoid control, allowing for easy and precise operation. It operates within a viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) and can withstand ambient temperatures from -40°C to +80°C (-40°F to +176°F). The DCV58 series is available with 2 spools and is a reliable and durable choice for demanding applications. It is commonly used in telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, mini-excavators, skid steer loaders, compact wheel loaders, wheel loaders, and backhoe loaders.
