1-Spool Hydraulic Valve | SD14 Model | Factory Direct & Customizable

Steuermethode:Manuell

Steuerkolben:1 Spule

Nennfluss:120 L/min (31,7 US gpm)

Maximaldruck:305 bar (4400 psi)

Einlassanschluss:G3/4

Auslassanschluss:G3/4

Anschlussgröße:G3/4

Hersteller:BXHS

Produkttyp:Monoblock-Wegeventil

Produktserie:SD14 Serie Monoblock-Wegeventil

Verpackungsgröße:15*26*15

Bruttogewicht:6.80 kg

Verfügbarkeit: Auf Lager

1078 Personen sehen sich dieses Produkt an

1-Spool Hydraulic Valve | SD14 Model | Factory Direct & Customizable

1-Spool Hydraulic Valve | SD14 Model | Factory Direct & Customizable

1-Spool Hydraulic Valve | SD14 Model | Factory Direct & Customizable drawing image

The SD14 Series Hydraulic Sectional Valve is a high-performance, 1-spool monoblock valve designed for demanding applications in material handling, construction, agriculture, and industrial vehicles. Featuring manual control and a rated flow of 120 L/min (31.7 US gpm), this valve is ideal for telehandlers, forklifts, excavators, loaders, and other mobile equipment.

SD14 Serie Monoblock-Wegeventil Parameter
Steuermethode Manuell, Pneumatisch, Hydraulisch
Steuerkolben 1 Spule
Umgebungstemperaturbereich -40 °C bis +60 °C (-40 °F bis +140 °F)
Strukturtyp Monoblockventil
Abschnitt 1 Abschnitt
Bereich der Betriebsviskosität 15 - 75 mm²/s (15 cSt bis 75 cSt)
Nennfluss 120 L/min (31,7 US gpm)
Maximaldruck 315 bar (4600 psi)
Einlassanschluss G3/4
Auslassanschluss G3/4
Anschlussgröße G3/4

This SD14 Series Hydraulic Sectional Valve is a robust, reliable, and customizable solution for your hydraulic system needs. It features a monoblock construction for increased strength and durability. With a rated flow of 120 L/min (31.7 US gpm) and a maximum pressure of 315 bar (4600 psi), this valve delivers the power and performance you need for demanding applications. This valve is designed for a wide range of operating temperatures (-40°C to +60°C) and viscosities (15 - 75 mm²/s), ensuring reliable operation in various environments. Available directly from our factory, you can customize this valve to meet your specific requirements. Our SD14 Series Hydraulic Sectional Valve is suitable for a wide range of applications, including: Telehandlers, Forklifts, All Terrain Cranes, Stackers, Aerial Platforms, Motor Graders, Midi-Excavators, Mini-Excavators, Skid Steer Loaders, and Compact Wheel Loaders. Contact us today to discuss your specific needs and get a customized solution.
